Product Features
Color: Gray
Warranty: 10-Year Limited
Electrical Specifications
Amperage: 200 A
Short Circuit Current Rating: 22 KA
Spaces / Circuits: 42 / 42
Type of Load Center: Main Breaker
Voltage: 120/240 VAC
Mechanical Specifications
Busbar Material: Copper, Bright Tin-Plated
Busbar Rating: 225A
Dimensions: 43.5" H x 15" W x 4.4" D
Enclosure Material: Galvanized Steel, Gray Baked Enamel
Ground Connection: 4 AWG - 2/0 AWG Cu/Al
Supply Connections: 3 AWG - 300 MCM Cu/Al
Weight: 59.8 lbs
Environmental Specifications
NEMA Enclosure Type: NEMA 3R Outdoor
Operating Temperature: 0°C to 40°C
Standards & Certifications
UL 50: Yes
UL 50E: Yes
UL 67: Yes
UL 869A: Yes
