*Actual product may vary from image shown

Leviton Ivory Stack Single Pole Switch

LEV 5224-2I
IN STOCK
$13.77
  • Packaging: EA
  • Brand Features

    With Leviton’s extensive assortment of combination devices, you can fill a one-gang space with two switches, a switch and receptacle, even a switch and GFCI. From sensor guide lights to multi-purpose styles and Tamper-Resistant receptacles, we accommodate your every need. These devices come in a range of colors and are backed by a limited two-year warranty. Built to last and designed to save space, these attractively styled devices are at home in any setting.

    Item Description

    15 Amp, 120/277 Volt, Duplex Style Single-Pole / Single-Pole AC Combination Switch, Commercial Grade, Grounding, Side Wired, - Ivory

    • AC Horsepower Ratings
    • HP Rating: 1/2HP-120V 2HP-240V-277V
    • Max. Amperage: 12 Amp
    • Electrical Specifications
    • Grounding: Grounding
    • Switch Amperage: 15 Amp
    • Switch Voltage: 120/277V AC
    • Dielectric Voltage: Withstands 1500V for 1 minute
    • Overload UL20 Test: 100 cycles of OL at 4.8 times rated current
    • Temperature Rise: Maximum 30 degrees C rise
    • Environmental Specifications
    • Flammability: Rated V-2 per UL94
    • Operating Temperature: -40ºC to 65ºC
    • Material Specifications
    • Actuator Material: Thermoplastic
    • Body Material: Thermoplastic
    • Strap Material: Steel
    • Color: Ivory
    • Mechanical Specifications
    • Termination: Side
    • Terminal ID: Brass-Hot Black-Hot White-Neutral Green-Gnd
    • Terminal Accom.: 14-12 AWG
    • Product ID: Stamped on Strap
    • Torque Range: 12-14 inch pounds
    • Product Features
    • HP Rating: 1/2HP-120V 2HP-240V-277V
    • Color: Ivory
    • Warranty: 10-Year Limited
    • Standards and Certifications
    • NEMA: WD-1 & WD-6
    • ANSI: C-73
    • UL Standard: UL 20
    • CSA C22.2 No. 111: File #152105
    • NOM: 057
    • Warranty: 10-Year Limited
