Klein Tools HVAC Electrical Test Kit

KLE CL320KIT
IN STOCK
  • PICKUP OR STORE DELIVERY ONLY
  • $120.39
    Length: 12.00
  • Packaging: EA
    • HVAC Kit with testers for the HVAC Professional; Cat. No. CL320 HVAC Digital Clamp Meter with AC Auto-Ranging, Cat. No. IR07 Dual IR/Probe Thermometer, and Cat. No. NCVT3P Dual Range Non-Contact Voltage Tester with Flashlight
    • HVAC Clamp Meter Cat. No. CL320 with TRMS measurement technology measures AC current, NCVT, AC/DC voltage, resistance, frequency, DC microamps, capacitance, duty cycle, diode test, continuity, and temperature
    • Cat. No. IR07 Dual IR Probe and Thermometer measures temperature from -40 to 572 Degrees Fahrenheit (-40 to 300 Degrees Celsius); accurately measure surface temperature with Infrared Thermometer (DS ratio 8:1)
    • Measure air vents and duct temperature using temperature probe with hands-free hanging hook; calculate differential temperature (T1-T2) for both IR and probe temperatures; IR07 is not a medical device and is NOT intended for use on people or animals
    • Cat. No. NCVT3P is dual-range and detects from 12 to 1000 V AC or 70 to 1000V AC for a broad variety of low-voltage or standard voltage applications; detects voltage with simultaneous visual and audible voltage indicators
    • Bright flashlight illuminates work area and may be used independent of voltage detection function; CAT IV 1000V rating provides expanded operation and protection

    Klein Tools HVAC Electrical Test Kit features Cat. No. CL320 Auto-Ranging, TRMS (True Root Mean Square), 400A HVAC Clamp Meter; Cat. No. IR07 Dual IR and Probe Thermometer, for both surface and air temperature measurements; and Cat. No. NCVT3P Dual Range Non-Contact Voltage Tester With Flashlight, for detection of AC voltage from 12 to 1000V with visual and audible indicators. Included is a convenient carrying pouch, test leads with CAT III/CAT IV safety caps, thermocouple, and all batteries.

    Specifications
    Type:  HVAC Testers
    Application:  HVAC Electrical and Temperature Testing
    Special Features:  Cat. No. CL320: Automatically Ranging True Root Mean Squared (TRMS) Measurement Technology; CAT. No. NCVT3P: NCVT with flashlight; Cat.No. IR07 Both IR and Probe Temperature
    Material:  ABS/Electronics
    Batteries:  7 x AAA
    Auto-Power Off:  Yes
    Jaw Size:  1.6'' (4.1 cm)
    Drop Protection:  6.6' (2 m)
    Display:  4000 Count Backlit LCD
    Functions:  TRMS, AC Current, NCVT, AC/DC Voltage, Resistance, DC microamp, Frequency, Capacitance, Duty Cycle, Diode Test, Continuity, and Temperature
    Voltage:  Cat. No. CL320: 600V AC/DC; Cat. No. NCVT3P: 1000V AC
    Frequency:  10 Hz to1 MHz
    Current:  400 A AC
    Capacitance:  4000 µF
    Ohms (Resistance):  40MO
    AC Voltage:  600V
    DC Voltage:  600V
    DC Polarity Indicator:  Yes
    DC Micro-Amp:  200 ?A
    Temperature Range:  -40° to 1832°F (-40° to 1000°C)
    Standard:  Cat. No CL320: CATIII 600V, Class 2, Double Insulation Safety Rating, CE Certified; Cat. No. NCVT3P: CAT IV 1000
    Included:  CL320 Digital Clamp Meter with Test Leads and Thermocouple; IR07 Dual IR and Probe Thermometer; NCVT3P Dual Range Non-Contact Voltage Tester with Flashlight; Carrying Pouch; Instructions; and All Required Batteries
    Overall Length:  8.45'' (21.5 cm)
    Overall Height:  1.5'' (3.8 cm)
    Overall Width:  3.5'' (8.9 cm)
    Weight:  1.575 lb (0.7 kg)
    UPC:  092644693496
